EUROCOM A110EU Service Manual page 34

Disassembly
Removing the 2.5" (63.5mm) HDD or SSD
Figure 6
1. Remove the battery
2.5" HDD or SSD
2. The hard disk is located at point
Removal
3. Remove screws
screwdriver to do this, due to the delicate nature of the screws).
a. Locate the hard disk
assembly 4. Lift the HDD assembly
b. Remove the screws.
c. Lift the hard disk as-
sembly out of the
computer.

4. Hard Disk Assembly
• 2 Screws
2 - 10 Removing the Hard Disk Drive
(page 2 - 5) and rear top cover
(
Figure 7a
1
& from the bracket (make sure you use a small manual screwdriver and not an electrical
2 3
out of the computer.
4 6
a.
c.
(page 2 - 7).
)
.
b.
1
4
2
3
