Interface
Four USB 2.0 Ports
Two USB 3.0 Ports
One HDMI-In Port
One HDMI-Out Port
One Headphone-Out Jack
One Microphone-In Jack
Two RS232 Serial (COM) Ports
Two PS/2 Ports
One RJ-45 LAN Jack
One DC-in Jack
Slots
One Slot for WLAN Module or Combo WLAN and Blue-
tooth Module
One ExpressCard/34(54) Slot
Card Reader
Embedded Multi-in-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
MS (Memory Stick) / MS Pro / MS Duo
Communication
Built-In Gigabit Ethernet LAN
(Factory Option) 2.0M FHD PC Camera Module
WLAN/ Bluetooth Half Mini-Card Modules:
(Factory Option) Intel® Centrino® Wireless-N 2230 Wire-
less LAN (802.11b/g/n) + Bluetooth 4.0
(Factory Option) Third-Party Wireless LAN (802.11b/g/n)
(Factory Option) Third-Party Wireless LAN (802.11b/g/n) +
Bluetooth 4.0
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 6.3A (120W)
(Factory Option) 6 Cell Smart Lithium-Ion Battery Pack,
62.16WH
Envionmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
525mm (w) * 49mm (d) * 418mm (h))
Around 7kg (with ODD)
