Removing The Stand - EUROCOM A110EU Service Manual

Wall Mounting Info

Removing the Stand

Figure 1
1. Turn off the computer and disconnect all cables and peripherals.
Stand Removal
2. Carefully place the computer flat with the LCD facing down (make sure you cover the LCD to avoid scratches) so
that you may access the rear cover.
a. Push to release the
3. Push at point
stand cover.
b. Remove the screws 4. Lift the stand cover
c. Remove the stand.
5. Remove the stand
a.

C. Stand Cover
L. Stand
• 8 Screws
C - 2 Removing the Stand
to release the stand cover in the direction of the arrow
A
off the computer and remove screws
C 6
( ).
Figure 1b
L 6
b.
A A
B
(Figure
B
- from the stand
D K
c.
C
D E F G
H I J K

Stand & Screws
Make sure you keep the stand
and removed screws in a safe
place in case you need to re-at-
tach the stand at a later date.
1a).
( )
Figure 1b .
L
