Introduction

Specifications


Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.

CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
1 - 2 Specifications
Processor Options
Intel® Core™ i7 Processor
i7-3770S (3.10GHz)
8MB L3 Cache, 22nm, DDR3-1600MHz, TDP 65W
i7-3570S (3.10GHz)
6MB L3 Cache, 22nm, DDR3-1600MHz, TDP 65W
Intel® Core™ i5 Processor
i5-3550S (3.00GHz), i5-3475S (2.90GHz), i5-3470S
(2.90GHz), i5-3450S (2.80GHz), i5-3570T (2.30GHz)
6MB L3 Cache, 22nm, DDR3-1600MHz, TDP 65W
Intel® Pentium® Processor
G640 (2.80GHz)
3MB L3 Cache, 22nm, DDR3-1066MHz, TDP 65W
Intel® Celeron® Processor
G540 (2.50GHz)
2MB L3 Cache, 22nm, DDR3-1066MHz, TDP 65W
Core Logic
Intel® HM61 Chipset
BIOS
One 48Mb SPI Flash ROM
AMI BIOS
Memory
Two 204 Pin SO-DIMM Sockets Supporting DDR3 1333/
1600MHz Memory
Memory Expandable up to 8GB
Storage
(Factory Option) One Changeable 12.7mm(h) Optical
Device Type Drive (Super Multi Drive Module or
Blu-Ray Combo Drive Module)
One Changeable 2.5" 9.5mm (h) SATA (Serial) HDD
One Changeable 3.5" 25mm (h) SATA (Serial) HDD
Video Adapter
Intel Integrated GPU
(GPU is Dependent on Processor)
Intel® HD Graphics
Dynamic Frequency (Intel Dynamic Video Memory Technol-
ogy for up to 1.7GB)
Microsoft DirectX®10 Compatible
Intel® HD Graphics 2500
Dynamic Frequency (Intel Dynamic Video Memory Technol-
ogy for up to 1.7GB)
Microsoft DirectX®11 Compatible
Intel® HD Graphics 4000
Dynamic Frequency (Intel Dynamic Video Memory Technol-
ogy for up to 1.7GB)
Microsoft DirectX®11 Compatible
LCD
21.5" (54,61cm) FHD
Audio
High Definition Audio Compliant Interface
Built-In Microphone
2 * Built-In Speakers
Security
BIOS Password
Security (Kensington® Type) Lock Slot
TPM 1.2
