EUROCOM A110EU Service Manual page 43

5. Press down and hold the latch
6. Move the latch and bracket
D
7. Carefully (it may be hot) lift the CPU
8. See page 2 - 20 for information on inserting a new CPU.
9. When inserting a CPU, pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!).
d.
f.
F
(with the latch held down, you will be able to release it)
C
fully in the direction indicated to unlock the CPU.
E
(
up out of the socket
F 6
e.
C
(
Figure 14d
)
Figure 14e .
D
Disassembly
)
.
Figure 14
CPU Removal
(cont'd)
d. Press and hold the
latch.
e. Move the latch and
bracket fully in the di-
rection to unlock the
CPU.
f. Remove the CPU.
E

F. CPU
Removing the CPU 2 - 19
