Removing the Rear Top Cover

Before undertaking any upgrade procedure it is necessary to remove the rear top cover to access the components.
1. Turn off the computer and disconnect all cables and peripherals.
2. Carefully place the computer flat with the LCD facing down (make sure you cover the LCD to avoid scratches) so
that you may access the rear cover.
3. Remove screws & ( Figure 3a
A B
4. Slide the rear top cover in the direction of the arrow
the marker on the side of the computer
5. Carefully remove the rear cover
a.
A
b.
D
D
) .
until the bottom marker of the rear cover icon is aligned with
C
( Figure 3b ) .
D
and set it aside ( Figure 3c
6 E
B
D
C
D
) .
c.
E
Disassembly
Figure 3
Rear Top Cover
Removal
a. Remove the screws.
b. Slide the rear top cov-
er to unlock.
c. Remove the rear top
cover.

E. Rear Top Cover
• 4 Screws
Removing the Rear Top Cover 2 - 7
