EUROCOM M660N Service Manual page 35

5. Turn the release latch towards the unlock symbol
7
6. Carefully (it may be hot) lift the CPU
7. Reverse the process to install a new CPU.
8. When re-inserting the CPU, pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!).
d.
e.
All manuals and user guides at all-guides.com
, to release the CPU
8 up out of the socket (Figure
7
Unlock
8
The heat sink, and CPU area in
general, contains parts which are
subject to high temperatures. Allow
the area time to cool before remov-
ing these parts.
(Figure d).
e).
7
Lock
Caution
Disassembly
Figure 7
Processor Removal
(cont'd)
d. Turn the release latch to
unlock the CPU.
e. Lift the CPU out of the
socket.
8. CPU
Removing the Processor 2 - 11
