EUROCOM M660N Service Manual page 31

4. Carefully grip the mylar tag
(
5. Lift the hard disk up Figure d
-
6. Remove the screws
6 7
7. Reverse the process to install any new hard disk.
c.
5
All manuals and user guides at all-guides.com
and slide the hard disk in the direction of arrow .
5
)
in the direction of arrow.
and separate the mylar from the hard disk
6 8
d.
.
9 6
e.
6
7
8
9
Removing the Hard Disk Drive 2 - 7
Disassembly
Figure 3
HDD Assembly
Sequence
Removal
c. Slide the HDD in the di-
rection of the arrow.
d. Lift the HDD out of the
bay.
e. Remove the screws and
separate the mylar from
the HDD.
8. Mylar
9. HDD
