Introduction
Feature
Power
Battery
Environmental
Spec
Dimensions
& Weight
Optional

Model Differences

The models vary slightly in external cover design and color.
Figure 1
Model difference
1 - 4 System Specifications
All manuals and user guides at all-guides.com
Full Range AC/DC Adapter 19V, 3.42A, 100~240V, 47~63Hz
Full Range AC/DC Adapter 20V, 4.5A (90 Watts), 100~240V, 50~60Hz (Supplied for the Optional Port Replicator
Only)
For Model A Computers Only
6 Cell Smart Lithium-Ion Battery Pack, 4400mAH (48.8W)
Temperature
° °
Operating: 5 C ~ 35 C
Non-Operating: -20°C ~ 60°C
360mm (w) * 267mm (d) * 25.4-34mm (h)
Optical Drive Module Options:
DVD/CD-RW Combo Drive Module
DVD-Dual Drive Module
(Factory Option) Port Replicator (10/100 Base-T
Ethernet Port, 4 * USB 2.0 Ports, Serial Port, Parallel
Port, External Monitor Port, DC-In Jack)
(Note: Port Replicator requires the supplied 90W
power adapter)
M660N
Specification
For Model B Computers Only
6 Cell Smart Lithium-Ion Battery Pack, 4000mAH (44.4W)
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
2.6 kg With 6 Cell Battery and DVD-ROM
Intel PRO/Wireless 3945ABG PCIe Wireless LAN Module
6 Cell Smart Lithium-Ion Battery Pack
300K or 1.3M Pixel USB 2.0 PC Camera Module
(Factory Option)
USB (2.0) Bluetooth Module - Version 2.0 (Factory
Option)
USB Floppy Disk Drive (Factory Option)
M665N
