CD Automation Revo Revex 2PH Series User Manual page 39

REVEX
2PH from 60A to 90A
Parameter Name
Indicates the percent of full scale measured
Analog In 1
by analog input 1
Indicates the percent of full scale measured
Analog In 2
by analog input 2
Indicates the software version number (x.xx.x)
Version
Indicates the software release date year and
Release
week (yyww)
Unit Type Indicates the type of power controller
Parameter Name
Indicates the maximum voltage rating of the
Max Voltage
power controller
Indicates the maximum current capacity of
Max Current
the power controller
Indicates the measured line voltage
Aux Voltage
Indicates the serial number of the power
Serial Number
controller
Indicates whether the SCR is below or above
SCR Temperature
the factory-set trip point
Description
Option
1 Leg Single Phase
2 Leg Two Leg, three phase
3 Leg Three Leg, three phase
3 Leg PA Three Leg, three phase with phase angle capability
Description
Option
Disabled No sensor present / temperature below limit
Over Temp Over temperature
Range
0 to 100.0
0 to 100.0
0 to 65535
0 to 65535
Description
Range
0 to 1023
0 to 9999
0 to 1023
0 to 9999
Description
39
User's manual
Modbus Par.
Unit
Address Type
Read
% 138
Only
Read
% 137
Only
Read
48
Only
Read
49
Only
Read
36
Only
Value
7
8
9
9999
Modbus Par.
Unit
Address Type
Read
V 41
Only
Read
A 62
Only
Read
V 43
Only
149-150 Read
151-152 Only
Read
127
Only
Value
0
130
