REVEX
2PH from 60A to 90A
9.4.2 Setup Menu
This section describes each item on the setup menu. Use this menu to configure the power controller for the
load. The password to access this menu is 2.
Parameter Name
Set the percentage by which the set point is
scaled. For example, if a 0 to 10V analog input
Out Scale
providing the set point is 5V and output scaling is
80% then the effective set point is 40%
100
80
60
40
20
0
0 20
Parameter Name
Set the nominal value for the line
Nominal V
voltage input
Nominal I Set the nominal load current
Choose the source for the remote
Remote SP
set point
Description
40 60 80 100
Input
Description
Option Value
Analog Input 1
Analog Input 2
Default
220V
Maximum
current
0
1
30
User's manual
Modbus
Range Unit
Address
0 to 100.0 % 16
Modbus
Range Unit
Address
0 to 1023 V 37
0 to 999.9 A 38
61
Par.
Type
Read
Write
Par.
Type
Read
Write
Read
Write
Read
Write
