REVEX
2PH from 60A to 90A
3

Quick Start

Attention: this procedure must be carried out by skilled people only.
If your REVEX code is in line with what you really need, then the main configuration is already done by Producer
and you just need to do the following steps:
1.
Verify REVEX current sizing. Be sure that:
• the load current is equal or less than the nominal one of REVEX
• the main voltage is equal or less than the nominal voltage of REVEX
2.
Verify the Installation
3.
Verify the Wiring:
• all auxiliary connections must be done in line with wirings on this manual
• verify that there isn't a short circuit on the load
4.
Supply the Unit
5.
Go in the Operator menu
Set the parameters Operative Load Voltage and Nominal Current of the load using the frontal keypad
or Thyristor configurator software.
The Unit is ready to work
The auxiliary voltage supply of the REVEX unit must be synchronized with load voltage power supply.
If the Auxiliary Voltage (written on the identification label) is different from Supply Voltage (to the load), use an
external transformer.
IMPORTANT!
Starting Strategy (Enable):
1: Feed the unit with L1-L2-L3 power voltage supply
2: Feed the auxiliary supply
3: Close the Enable contact to start with the regulation
If your REVEX code is NOT in line with what you really need, use the configurator software tool to set-up
the unit. Install the software on your PC, select REVEX and click on test unit changing what you need.
