9.4.4 Hardware Menu
This section describes each item on the hardware menu. Use this menu to configure how the inputs and
outputs are used in the application. The password to access this menu is 5.
Parameter Name
Choose the type of signal to be measured by
Analog In 1
analog input 1
Parameter Name
Choose the type of signal to be measured by
Analog In 2
analog input 2
Parameter Name
Analog In 2 Choose how the signal measured by analog input
2 is used
Function
Description
Option
0-10V / 10k Pot 0 to 10 Vdc or 10,000Ω
4-20mA 4 to 20 mAdc
0-20mA 0 to 20 mAdc
DEFAULT: 0-10V / 10k Pot
Description
Option
0-10V / 10k Pot 0 to 10 Vdc or 10,000Ω
4-20mA 4 to 20 mAdc
0-20mA 0 to 20 mAdc
DEFAULT: 0-10V / 10k Pot
Description
Option
Feed-back External feed-back
Set Point Power Demand set point
DEFAULT: Feed-back
