REVEX
2PH from 60A to 90A
Parameter Name
Set the gain for the main loop. A
smaller proportional band yields
Prop band power
a larger adjustment for a given
deviation
Set how aggressively the integral
part of the control algorithm acts.
Integral power A smaller settings yields a larger
adjustment for a given deviation over
a given time
Set the threshold of resistance that
Htr Break activates the Heater Break alarm.
This setting is in percentage of the
sensitivity
nominal load resistance
Set a delay between when the
resistance drops below the value
set for a heater break sensitivity
Htr Break delay
and when the heater break alarm
is indicated. This set increments of
50mSec
Description
32
Default Range
10% 0 to 255
50 0 to 255
100% 0 to 100.0
0 to 255
50 (2,5
(0 to 12,75
sec)
sec)
User's manual
Modbus Par.
Unit
Address Type
Read
% 26
Write
Read
27
Write
Read
% 29
Write
Read
28
Write
