Port Overview; Interface Description; Engineering Interface; Windows Interface - SEW-Eurodrive MOVI-C CONTROLLER UHX65A Manual

10.3

Port overview

10.3.1

Interface description

The Ethernet interfaces of the MOVI‑C
•
•
•
10.3.2

Engineering interface

Port TCP/ Function
UDP
21 TCP FTP
23 TCP Telnet
310 TCP/ Data Streaming
UDP
11740 – TCP CODESYS engineering
11743
1740 - 1743 UDP CODESYS engineering
10.3.3

Windows interface

Depending on the installation and configuration of the Windows operating system and
of additionally installed software components, the following ports are available, among
others:
Port TCP/UDP Function
7 TCP/UDP Echo
9 TCP/UDP Discard
13 TCP/UDP Daytime
17 TCP/UDP Quote of the day
19 TCP/UDP Character generator protocol
135 TCP
139 TCP
161 UDP
300 TCP/UDP SMLP
445 TCP
500 UDP
515 TCP
3389 TCP
4500 UDP
5355 UDP
® PLUS
X30 – EtherCAT /SBus
X80/X82 – Engineering interface for the control section
X90 – Engineering interface for the Windows section
Microsoft EPMAP (End Point Mapper)/DCE/RPC Locator Service
Microsoft EPMAP (End Point Mapper)/DCE/RPC Locator Service
SNMP
Microsoft-DS SMB release (also known as the free implementation Samba)
Internet Security Association and Key Management Protocol (ISAKMP)
Line Printer Daemon print services
Microsoft Terminal Server (RDP), officially registered as Windows Based Ter-
minal (WBT)
IPSec NAT Traversal (RFC 3947)
LLMNR – Link-Local Multicast Name Resolution
®
CONTROLLER have the following functions:
interface for master connection
Authorization
Reading from and writing to the file system
Reading OEM diagnostic data
Reading and writing of all indexed parameters
Read and write
Read and write
®
Manual – MOVI‑C CONTROLLER progressive UHX65A
Technical data
10
Port overview
55
