4.3.2

Description of terminal functions

No. Designation
[1] Connection of DC 24 V voltage sup-
ply (−)
Connection of DC 24 V voltage sup-
ply (+)
® PLUS
[2] EtherCAT /SBus
(RJ45 socket)
[3] Engineering interface
(RJ45 socket)
[4] DisplayPort interface
[5] Engineering interface
(RJ45 socket)
[6] Engineering interface
(RJ45 socket)
A
X5
[1]
X30
[2]
[3]
X82
[4]
A: View from top
Terminal
X5: PIN1
X5: PIN2
interface X30
X82
DP
X90
X80
24V
X90
X80
[7]
W: View from front
Function
Voltage supply DC 24 V
® PLUS
EtherCAT /SBus master connection
Engineering interface for the control section
Monitor connection
Engineering interface for the Windows section
Engineering interface for the control section
®
Manual – MOVI‑C CONTROLLER progressive UHX65A
Installation notes
Electrical installation
B
L1
L2
L3
[5]
[6]
XM2
USB1
USB2
[8]
XM1
USB3
[9]
