Wilding Wallbeds C90 Installation Instructions Manual

Hide thumbs

page of 20

/ 20
Bookmarks

Quick Links

Download this manual

For Wallbed models:

Do-It-Yourself

WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND

FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SE-

VERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER

SERVICE AT 866-725-6401 FOR ANY QUESTIONS.

INSTALLATION INSTRUCTIONS

BOOKLET #C90

Revision 6/18 BKC90

Need help?

Do you have a question about the C90 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wilding Wallbeds C90

Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS For Wallbed models: BOOKLET #C90 Do-It-Yourself WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SE- VERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT 866-725-6401 FOR ANY QUESTIONS.
Page 3 ATTENTION Step 1: Complete first 3 pages to apply edge taping...
Page 4 Measure length to be edge taped and cut the tape 2” longer than dimension. With a hot iron apply tape slowly making sure the tape fully adheres to the bed part. Leave edge tape one inch long on both ends. Once edge tape is securely glued to the bed part use an edge tape trimmer to trim edge tape flush on both sides.
Page 5 Apply iron on edge tape to this edge Apply iron on edge Apply iron on edge tape to this edge tape to this edge...
Page 6 Caution: Study carefully the illustrations before applying edge tape. Note that all illustrations reveal cam fitting sockets. Additionally note that the Bridge board has 4 cam sockets on one side. Apply iron on edge tape to this edge Note 4 cam sockets Bridge Board Apply iron on edge tape to this edge...
Page 7 ATTENTION Step 2: Complete the remaining 12 pages for installation...
Page 8 studsensor...
Page 10 Step 1: Locate the two Side Boards. If you purchased a Queen size bed the Side Boards measure 85” long. Full and Twin size Side boards will measure 80” long. From the square white box locate the two Lift Mecha- nisms, hardware bags and springs.
Page 11 Hardware needed for next step from Pack #2 5/16” x 1 1/4” Flathead 5/16” Nylock Nut Slot Machine Screw Step 2-B: Install the Lift Mechanism by inserting a 5/16” x 1 1/4” Flathead Machine Screw through holes A, B, C and D from the outside (countersunk holes) of the Right Side Board.
Page 14 Step 10: Locate the Front Panel(s) and lay them on the floor face down (finished side). Position them in front of where the Bed Cabinet was installed and leave enough room to work around them. Foot rail Step 11: Arrange the mat- tress rails on the face panels as shown.
Page 15 Step 12: From hardware pack 3 locate the hardware shown above. Finger tighten the hardware as shown in illustration 7 attaching two of the 4 hole corner brackets on the foot rail end of the mattress frame. Note the lower hole on each side rail uses the Leg Stop with the longer screw (3/16”...
Page 18 Step 22: Stand the Bed face unit up on its Head Rail end. Now with you and your assistant on either side of the Bed face unit lift until the # 3 bolt on the Bed face unit is a few inches above the Bed Front slotted end of the Tension Arm on both sides.
Page 19 Page 10...
Page 20 Step 25: Place Handles as desired on Wallbed Note: Positioning the handles more toward the top of the bed face will make the bed easier to open.
