INSTRUCTION BOOKLET #C20
Watch step by step installation instructions at:
https://www.wallbedsbywilding.com/wallbed-installation-studio-series/
WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND
FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SE-
VERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER
SERVICE AT 866-725-6401 FOR ANY QUESTIONS.
Revision 8/18 C20
Advertisement
Related Manuals for Wilding Wallbeds Studio Series
Summary of Contents for Wilding Wallbeds Studio Series
- Page 1 INSTRUCTION BOOKLET #C20 Watch step by step installation instructions at: https://www.wallbedsbywilding.com/wallbed-installation-studio-series/ WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SE- VERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT 866-725-6401 FOR ANY QUESTIONS.
- Page 3 Studsensor...
- Page 5 Step 1: Locate the two Side Boards. If you pur- chased a Queen size bed the Side Boards measure 85.25” long. Full and Twin size Side boards will measure 80.25” long. Then from the small square cardboard box locate the two Lift Mechanisms, hardware bags, and springs.
- Page 6 Step 4: Lay the right and left Side Boards down as illustrated and screw the Connecting Bolts into the holes provided as il- lustrated. Note: Screw the connecting bolts down until the collar of the connecting bolt is seated firmly against the surface of the wood.
- Page 7 Head Boards have 2 options. Option 1 is for a “standard depth” Wallbed and Option 2 is for an “Extra Deep” Wallbed. Determine which Wallbed kit you have and then proceed with the correct option below. OPTION 1 OPTION 2 STANDARD DEPTH HEAD BOARD EXTRA DEEP HEAD BOARD Page 3...
- Page 9 Step 7: : Using a Stud Finder locate and mark the studs in your wall behind the Bed Cabinet. At- Studs in your wall tach “L” brackets to the top, back of the Bed Cabinet using 3/4” Pan Head screws corresponding to where the studs are located in your wall.
- Page 11 Step 10: From hardware pack 3 locate the hardware shown above. Finger tighten the hardware as shown in illustration 7 connecting the Foot Rail to the Side Rail using the 4 hole corner bracket. Note the lower hole on each Side Rail uses the Leg Stop with the longer screw (1 1/4”...
- Page 12 Hardware and parts needed for next steps x 160 5/8” Square Pan head screw (Hardware pack #7)
- Page 14 Step 15 ; Attach the Velcro Strap that is used for holding the mattress in place while wall bed is closed. First remove one of the 5/8” Pan head screws that attaches the rail to the Face Panels on each Side Rail of the frame at about 18” from the Foot Rail of the frame.
- Page 16 Page 12...
- Page 17 Step 21: Insert a 5/16” x 1” Hex Head bolt through hole #2 and tighten a 5/16” Nylock nut onto the bolt. Now tighten the nut and bolt in hole #3. Repeat step on the other side of the bed unit.
- Page 18 Step 23: When the bed is closed check to see if the gap Illustration 12 on either side is the same. If it looks right skip this step. If the gap is not right, meaning that the Bed Box is too close to the side board or even touching it at the top on one side it will need to be adjusted.
