Side Mount
INSTRUCTION BOOKLET #C22
WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND
FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SEVERE
PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT
866-725-6401 FOR ANY QUESTIONS.
Revision 1.19
Advertisement
Related Manuals for Wilding Wallbeds Side Mount
Summary of Contents for Wilding Wallbeds Side Mount
- Page 1 Side Mount INSTRUCTION BOOKLET #C22 WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SEVERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT 866-725-6401 FOR ANY QUESTIONS.
-
Page 3: Tools Needed
Tools Needed Step Ladder studsensor... - Page 5 Step 1: Locate the left and right Side Boards and then from the small square cardboard box locate the two Lift Mechanisms, hardware bags, and springs. Left Side Board Right Side Board...
- Page 6 Bed Size Number of Springs Queen Full/Double Twin/Single...
- Page 7 Step 4: Lay the right and left Side Boards down as illustrated and screw the Connecting Bolts into the holes provided as il- lustrated. Note: Screw the connecting bolts down until the collar of the connecting bolt is seated firmly against the surface of the wood.
- Page 8 OPTION 1 OPTION 2 STANDARD DEPTH HEAD BOARD EXTRA DEEP HEAD BOARD Page 4...
- Page 9 Step 5: Assemble the Bed Cabinet face down with the bottom of the Bed Cabinet nearer the wall in which it will be installed. Note the “Front Stretcher” (illustrated below) should be positioned so the Cam Fittings are at the bottom of the Bed Cabinet. IMPORTANT! Tighten the cam fittings with a hand screw driver by turning the Phillips head clockwise 1/2 turn to tight.
- Page 10 Page 6...
- Page 11 Step 9: Locate the Front Bridge Support boards (two narrow pieces of wood connected together) and insert it between the Side Boards and on to the Connecting Bolts. Tighten all Cam Fittings. Page 7...
- Page 12 WARNING! THE NEXT STEP MAY REQUIRE PROFESSIONAL HELP. IF YOUR WALLS ARE NOT TRADITIONAL WOOD FRAMING, YOU MAY NEED TO HIRE A HANDY MAN OR CONTRACTOR TO HELP IN ANCHORING THE BED TO YOUR WALL. FAILURE TO PROP- ERLY ANCHOR THE CABINET COULD CAUSE SEVERE PERSONAL INJURY. CALL TECHNICAL SUPPORT AT 866-725-6401 IF YOU HAVE ANY QUESTIONS.
- Page 13 Step 12: Arrange the Mattress Rails on the face panels as shown. HELPFUL HINT: Side Mount beds can be slept on in either direction. The rails referred to as “Head/Foot rail” (identical) can act as either the head or foot of the bed, depending on which way a sleeper lies.
- Page 14 Step 13: From hardware pack 3 locate the hardware shown above. Finger tighten the hardware as shown in illustration 7 connecting the Outer Side rail to a Head/Foot rail using a 4 hole corner bracket. Note the lower hole on each Head/Foot rail uses the Leg Stop with the longer screw (1 1/4”...
- Page 15 Frame positioned evenly side to side with wood face panels protruding by approximately 1” on either side.
- Page 16 Hardware and parts needed for next steps Wood Mattress Support...
- Page 17 Hardware and parts needed for next steps 3/4” Washer (pack #5) Step 19 ; Attach the Velcro Strap that is used for holding the mattress in place while wall bed is closed. First remove one of the 5/8” Pan head screws that attaches the rail to the Face Panels on each side of the frame at about 18”...
- Page 18 Step 20: As illustrated below, insert the Allen Head Bolt through bolt hole # 1 and tighten it down securely using a Nylock Nut. Now insert a 5/16” x 1” Hex head bolt through hole # 3 and thread the Nylock nut ONLY UNTIL THE NUT IS FLUSH WITH THE END OF THE BOLT.
- Page 19 IMPORTANT! As instructed in step 20, Bolt #3 should be loose enough to slip into the notch at the end of the Tension Arm See illustration below. #3 Bolt head Step 24: Stand the Bed face unit up on its Inner Side Rail. Now with you and your assistant on either side of Tension Arm the Bed unit lift until the # 3 bolt on...
- Page 20 Step 25: Insert a 5/16” x 1” Hex Head bolt through hole #2 and tighten a 5/16” Nylock nut onto the bolt. Now tighten the nut and bolt in hole #3. Repeat step on the other side of the bed unit.
- Page 21 Push bed over at the bottom to align Page 17...
