Summary of Contents for Wilding Wallbeds Studio Series
Page 1
STORAGE HEAD BOARD INSTRUCTION BOOKLET #C23 Watch step by step installation instructions at: https://www.wallbedsbywilding.com/wallbed-installation-studio-series/ WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SE- VERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT 866-725-6401 FOR ANY QUESTIONS.
Page 5
Step 1: Locate the two Side Boards. If you purchased a Queen size bed the Side Boards measure 85.25” long. Full and Twin size Side boards will measure 80.25” long. Then from the small square cardboard box locate the two Lift Mechanisms, hardware bags, and springs.
Page 9
Step 6: Stand the Bed Cabinet up against the wall where you intend to have it installed. Page 5...
Page 10
Step: 7: Using a Stud Finder locate and mark the studs in your wall behind the Bed Cabinet. Attach the “L” brackets to the top, back of the Bed Cabinet cor- responding to where the studs are located. Now attach the “L” brackets to the studs in the wall using six 2”...
Page 11
Step 9: Arrange the Mattress Foot rail Rails on the face panels as shown. HELPFUL HINT: the “Head Rail” refers to the end that is closest to the Bed Cabinet during assembly and Side rail will be where your head is while Side rail sleeping.
Page 12
Step 10: From hardware pack 3 locate the hardware shown above. Finger tighten the hardware as shown in illustration 7 connecting the Foot Rail to the Side Rail using the 4 hole corner bracket. Note the lower hole on each Side Rail uses the Leg Stop with the longer screw (1 1/4”...
Page 13
Hardware and parts needed for next steps x 160 5/8” Square Pan head screw (Hardware pack #7)
Page 14
Hardware and parts needed for next steps 5/8” Square Pan head screw (Hardware pack #7)
Page 15
Step 15 ; Attach the Velcro Strap that is used for holding the mattress in place while wall bed is closed. First remove one of the 5/8” Pan head screws that attaches the rail to the Face Panels on each Side Rail of the frame at about 18” from the Foot Rail of the frame.
Page 16
Step 16: As illustrated below, insert the Allen Head Bolt through bolt hole # 1 and tighten it down securely using a Nylock Nut. Now insert a 5/16” x 1” Hex Head bolt through hole # 3 and thread the Nylock nut ONLY UNTIL THE NUT IS FLUSH WITH THE END OF THE BOLT.
Page 17
#3 Bolt head Tension Arm Bed Front Allen Key bolt head Optional Light kit safety cut off switch. Beds with Page 13 light kit only...
Page 18
Step 21: Insert a 5/16” x 1” Hex Head bolt through hole #2 and tighten a 5/16” Nylock nut onto the bolt. Now tighten the nut and bolt in hole #3. Repeat step 21 on the other side of the bed unit.
Page 19
Step 23: When the bed is closed check to see if the gap Illustration 12 on either side is the same. If it looks right skip this step. If the gap is not right, meaning that the Bed Box is too close to the side board or even touching it at the top on one side it will need to be adjusted.
