INSTRUCTION BOOKLET #C21 For Wallbed models: KING SIZE Watch step by step installation instructions at: https://www.wallbedsbywilding.com/wallbed-installation-studio-series/ WARNING! ALL MURPHY/WALLBED SYSTEMS CONTAIN STORED ENERGY. FAILURE TO USE AND FOLLOW THESE INSTRUCTIONS DURING THE INSTALLATION PROCESS COULD RESULT IN SEVERE PERSONAL INJURY TO USER OR DAMAGE TO PRODUCT. PLEASE CONTACT CUSTOMER SERVICE AT 866-725-6401 FOR ANY QUESTIONS.
Page 5
Tension Arm if you pry up the Arm Bracket with a wooden wedge or similar device. Continue by working down from, hole 1 (king size beds) or hole 2, (for queen size), until you have installed the required number of springs.
Page 6
Hardware needed for next step from Pack #2 5/16’’ x 1 1/4’’ 5/16’’ Nylock Nut...
Page 7
Head Boards have 2 options. Option 1 is for a “standard depth” Wallbed and Option 2 is for an “Extra Deep” Wallbed. Determine which Wallbed kit you have and then proceed with the correct option below. OPTION 1 OPTION 2 STANDARD DEPTH HEAD BOARD EXTRA DEEP HEAD BOARD Page 3...
Page 9
Step 7: : Using a Stud Finder locate and mark the studs in your wall behind the Bed Cabinet. At- Studs in your wall tach “L” brackets to the top, back of the Bed Cabinet using 3/4” Pan Head screws corresponding to where the studs are located in your wall.
Page 10
Foot rail Side rail Side rail Head rail...
Page 12
Hardware and parts needed for next steps x Approx. 118 5/8” Square Pan head screw (Hardware pack #7)
Page 13
Center Stiffeners FOOT RAIL 3.5” Stiffener #1 Stiffener #2 Stiffener #3 WARNING! DO NOT STRIP SCREWS. SCREWS SHOULD BE TIGHT BUT NOT STRIPPED. Stiffener #4 Stiffener #5 HEAD RAIL...
Page 15
Step 17: As illustrated below, insert the Allen Head Bolt through bolt hole # 1 and tighten it down securely using a Nylock Nut. Now insert a 5/16” x 1” Hex head bolt through hole # 3 and thread the Nylock nut ONLY UNTIL THE NUT IS FLUSH WITH THE END OF THE BOLT.
Page 16
IF YOU PURCHASED LIGHTS FOR YOUR WALLBED YOU MUST STOP RETURN TO THE LIGHT KIT INSTRUCTIONS STEP 6 AND INSTALL THE SAFETY CUT OFF DEVICE BEFORE MOVING ON. IMPORTANT! As instructed in step 17, Bolt #3 should be loose enough to slip into the notch at the end of the Tension Arm See illustration below.
Page 17
Step 22: Insert a 5/16” x 1” Hex Head bolt through hole #2 and tighten a 5/16” Nylock nut onto the bolt. Now tighten the nut and bolt in hole #3. Repeat step 22 on the other side of the bed unit.
Page 18
Illustration 12 Push bed over at the bottom to align 3/16”Drill 3/16”Drill...
