Programming Examples

Creating a Limit Line

Creating a Limit Line
This C programming example does the following:
• Open an HP-IB session at address 18.
• Clear the analyzer.
• Reset the analyzer.
• Set the input port to the 50 MHz amplitude reference.
• Delete any current limit line.
• Define the upper limit line to have frequency/amplitude pairs.
• Define the lower limit line to have frequency/amplitude pairs.
• Turn the limit line test function on.
• Set the analyzer to a center frequency of 50 MHz, span to 20 MHz,
and resolution bandwidth to 1 MHz.
• Turn the limit line test function on.
• Set the analyzer reference level to 0 dBm.
• Activate the 50 MHz Alignment signal.
• Check to see if limit line passes or fails. It should pass
• Pause for 5 seconds.
• Deactivate the 50 MHz alignment signal
• The limit line test should fail.
• Close the session.

Example:

#include <stdio.h>
#include <stdlib.h>
#include <math.h>
#include <conio.h>
#include <ctype.h>
#include <string.h>
#include <windows.h>
#include "visa.h"
#define YIELD Sleep(5000)
3-40 Chapter 3
