Err 09 Pump off
Heating off
Pump off
Err 10
Heating off
Err 11 Pump off
Heating off
Err 12 Pump off
Heating off
Pump off
Err 13
Heating off
Err 14 Pump off
Heating off
If the actions described fails to resolve the fault or another error code is displayed then take one of the following steps:
- Contact the service department;
- Send the device for repair, including a short description of the fault.
• Tubing, hoses, adapters and couplings:
Metal hose (isolated M16 x 1)
LT 5.20
LT 5.21 PTFE hose (isolated M16 x 1)
H.PVC.8 PVC hose (nominal width 8)
H.PVC.12 PVC hose (nominal width 12)
Silicone hose (nominal width 8)
H.SI.8
Silicone hose (nominal width 12)
H.SI.12
• Tubing Insulations:
Insulation (8 mm)
ISO. 8
ISO.12 Insulation (12 mm)
• Bath vessels:
IB eco 8 Plastic bath (8 litres)
IB eco 18 Plastic bath (18 litres)
IB pro 9 Stainless steel bath (9 litres)
Stainless steel bath (12 litres)
IB pro 12
IB pro 20 Stainless steel bath (20 litres)
• Bridges and Covers:
BS.ICC Small bridge (for IB eco 8, IB pro 9)
BL.ICC Large bridge (for IB eco 18, IB pro 12, IB pro 20)
CS.ICC Samll cover (for IB eco 8, IB pro 9)
Medium cover (for IB pro 12)
CM.ICC
Large cover (for IB eco 18, IB pro 20)
CL.ICC
• Additional accessories:
Pump set
PCS.ICC
PC 1.1 Cable (RS 232)
USB 2.0 cabel A - Micro B
®
Labworldsoft
See more accessories on www.ika.com.
Device internal temperature is too
high
PC communication failure
Temperature difference between
control sensor and safety sensor is
too much
Safety temperature alarm
Heater switched off by safety
circuit
Fan error

Accessories

- Check the ambient temperature and let the de-
vice cool down
- Check communication cable
- Check safety temperature circuit and bath fluid
- Check the bath temperature measurement
- Check safety temperature set value, fluid level
- Check the fan and clean the grids at the rear side
