3.12 CANALI DMX

5 CANALI
MODE
FUNCTION
5 Ch
DIMMER
1
0 - 100%
STROBE
2 No Function
Slow to fast
AUTO PROGRAMS
No Function
Auto 1
Auto 2
Auto 3
3 Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 0
AUTO SPEED
4
Slow to Fast
DIM MODE
Menu setting dimmer mode
Dimmer mode off
5
Dimmer mode 1
Dimmer mode 2
Dimmer mode 3
1 2 3
8 9 10
15 16 17
22 23 24
29 30 31
36 37 38
43 44 45
HALUPIX
DMX
Value
000 - 255
000 - 010
011 - 255
000 - 010
011 - 038
039 - 066
067 - 094
095 - 122
123 - 150
151 - 178
179 - 206
207 - 234
235 - 255
000 - 255
000 - 051
052 - 101
102 - 152
153 - 203
204 - 255
4 5 6 7
11 12 13 14
18 19 20 21
25 26 27 28
32 33 34 35
39 40 41 42
46 47 48 49
8 CANALI
MODE
FUNCTION
8 Ch
DIMMER
1
0 - 100%
STROBE
2 No Function
Slow to fast
FOREGROUND DIMMER
3
0 - 100%
BACKGROUND DIMMER
4
0 - 100%
ALPHANUMERIC
No Function
5
Numeric Characters 1 - 0
Alpha Characters A - Z
GOBO MAPS
No Function
Simple Cross (gobo 1)
Simple Box (gobo 2)
Square Imploder (gobo 3)
Square Exploder (gobo 4)
Diamond Imploder (gobo 5)
Diamond Exploder (gobo 6)
2 Line Spinner (gobo 7)
Triangle Spinner (gobo 8)
Tri-Downer (gobo 9)
Tri-Upper (gobo 10)
Bowtie Spinner (gobo 11)
One-Liner (gobo 12)
6 Line Hop UP (gobo 13)
Line Hop DOWN (gobo 14)
Line Hop UP DOWN (gobo 15)
T-Spin (gobo 16)
Upside Down T-Spin (gobo 17)
Diamond Spoke Spin (gobo 18)
Line Hop LEFT (gobo 19)
Line Hop RIGHT (gobo 20)
Line Hop LEFT RIGHT (gobo 21)
Double Verticals (gobo 22)
Double Horizontals (gobo 23)
Diagonal Right (gobo 24)
Diagonal Left (gobo 25)
Moving Squares (gobo 26)
Clock (gobo 27)
DMX
Value
000 - 255
000 - 010
011 - 255
000 - 255
000 - 255
000 - 000
001 - 127
128 - 255
000-010
011-020
021-029
030-038
039-047
048-056
057-065
066-074
075-083
084-092
093-101
102-110
111-119
120-128
129-137
138-146
147-155
156-164
165-173
174-182
183-191
192-200
201-209
210-218
219-227
228-236
237-246
247-255
