Test Run for Wireless Controller (CIR01)
After all installations are completed, a test run should be performed.
(1) Perform the test run according to the installation manual for the wireless controller.
(2) The test run for the wireless controller will take two hours to complete. If the TIMER indicator (green)
is flashing (0.5 second ON/0.5 second OFF) after two hours, an alarm may occur. Operate the indoor
unit and check for an abnormality.
Alarm Indication
● If a malfunction occurs, such as a safety device actuation, during the test run or the normal
operation, "RUN" (red light) flashes (0.5 second ON/0.5 second OFF).
● The alarm codes are indicated by the flashing of "DEF" (green light) and "FILTER" (yellow light).
The first LED light is green. The number of times this LED flashes (0.5 second ON and OFF)
will tell you the "DEF" Alarm Code.
The second LED light is yellow. The number of times this LED flashes (0.5 second ON and
OFF) will tell you the "FILTER" Alarm Code.
Example
3 5
Alarm
"DEF" flashes three times (0.5 second ON/ 0.5 second OFF)
"FILTER" flashes five times (0.5 second ON/ 0.5 second OFF)
● "RUN" (red light) flashing (1 second ON/1 second OFF) indicates an abnormal transmission (connector
loose, connector disconnection, broken wire or incorrect wiring, or something similar) between the
indoor unit and the IR receiver kit.
● When the IR receiver kit is connected to multiple indoor units, the alarm code is indicated for each
indoor unit in order.
[ Alarm Code Table ]
Further details for alarm codes can be found in the "Installation and Maintenance Manual" for the indoor unit.
TC-16002-rev.1
"FILTER" (yellow light)
"DEF" (green light)
These signals are repeated until the alarm is reset.
