Filter Box: B-90Hd - Johnson Controls VRF System Engineering Manual

3.4 Filter Box: B-90HD

Dimensional Data
Filter Holder (Resin)
Galvanized
Sheet Metal
Installation State
2-11/16 (68)
Installation
Height
Specifications
Item
Applicable Indoor Unit Model
((H,Y,C)IC2**B21S)
Quantity
Installation Height
Material
Accessory
Weight
Applicable Air Filter
(Option)
NOTES:
1. The total height of the unit is increased by approximately 2-11/16 inch (68mm) when the filter box is
installed. Therefore, pay attention to the size of the installation space.
2. The indoor unit and the filters shown in the figure are sold separately. Order them for each.
3. Refer to the "Installation and Maintenance Manual" of the filter box for details of installation of the filter box.
TC-16002-rev.1
33-7/16 (850)
Model
inch (mm)
lbs (kg)
Antibacterial Long Life Filter
(Gravimetric Method: 65%)
24-13/16 (630)
Air Inlet
Flat Grille
Long Life Filter
(Attached with
Optional Decorative Panel)
018 and 024
2-11/16 (68)
Polyethylenes, Galvanized Steel Plate
Screw, Hook Packing, Installation Manual
F-90MD-K1
OPTIONAL PARTS
Unit: inch (mm)
Packing
2-3/8 (60)
9/16 (15) (Before Compression)
5/16 (8) (After Compression)
2-11/16 (68) (Installation Height)
Indoor Unit
Air Filter
Filter Box (Option)
Ceiling
Decorative Panel
B-90HD
1
11 (5.0)
3-7
