3.2 Motion Sensor Kit: SOR-NED

Dimensional Data
Installation State
3-2
Connecting Cable (CN10)
(to Electrical Control Box of Indoor Unit)
Motion Sensor Kit (SOR-NED)
5-5/16 (135.4)
3-3/16 (81)
3-3/16
(81)
43-5/16 (1100)
Unit: inch (mm)
2
(50.5)
TC-16002-rev.1
