FEATURES
● Improvement of Energy-Saving
(1) Adopting High Efficient New Turbo Fan and DC Fan Motor
(2) Improvement of Heat Exchanger and Reduction of Airflow Loss
NEW
Improved Heat Exchanger
Optimized for excellent efficiency.
Energy-Efficient Fan Motor
NEW
(3) Improvement of Energy-Saving Operation by Adopting Motion Sensor
* Adopting Motion Sensor Function
- The motion sensor function can adjust the setting temperature according to human activity and it
controls the airflow volume and the airflow direction.
- The motion sensor function allows optimized energy-efficient control.
● New Design and High Performance Decorative Panel
Simple and Stylish Design
The decorative panel has a new, simple, but stylish design applicable to the air inlet flat grille. It can be
used as a shutter at the time of OFF operation.
2-way Individual Louver
Two louvers have individual adjustment capability with a newly equipped individual louver setting function.
Up
1-2
Fully Closed
Air Inlet Flat Grille
Swing
Turbo Fan
Horizontal
Air Outlet Angle
Downward
Air Outlet Angle
NEW
NEW
Improved Airflow Path with Smooth Air Inlet
