2.9 Electrical Data

Model
(H,Y,C)IC2018B21S
(H,Y,C)IC2024B21S
VOL: Rated Unit Power Supply Voltage (V)
PH: Phase
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
OPT: Rated Motor Output (kW)
FLA: Full Load Ampacity (A)
NOTE:
Power supply voltage should be satisfied with the following.
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
TC-16002-rev.1
Unit Main Power Applicable Voltage
VOL PH HZ Maximum Minimum
208/230 1 60
Power Supply
MCA
0.8
253 188
1.2
2-WAY CASSETTE
Indoor
Unit
Fan Motor
MFA OPT FLA
15 0.057
15 0.057
0.6
0.9
2-7
