2 Installation
Chapter 2 Installation
Note
Please read the safety notices carefully before installing and starting up your device. These are sup-
plied together with the device.
Refer to chapter
2.1 Setting up and connecting
Note
The device can be fitted with various antenna systems. External, screw-on standard antennas can be
used (optional).
APR222ac
Fig. 1:
When setting up and connecting the device, carry out the following steps in order:
(1) Antennas
Connect the antenna connectors to the antennas to be used with the device.
(2) Installation
Thanks to the brackets in the housing, the access points can be fitted to the wall or ceiling.
Wall-/Ceiling mounting
To attach the device to the wall/ceiling, the mounting brackets may be readily attached to the housing. They
are screwed to the wall/ceiling with six screws.
• Screw the mount to the wall with the 6 screws.
2
Technical data
on page 14.
- Connection options
Warning
Before drilling, make sure that there are no building installations nearby. If gas, electricity, water or
waste water lines are damaged, you may endanger your life or damage property.
Teldat SA
APR222ac
