6 Access and configuration
Symbol
You can select the following operating functions in the list view:
GUI list options
Menu
Update Interval
Filter
Configuration elements
Fig. 16: Configuration of the update interval
Fig. 17: Filter list
Structure of the GUI configuration menu
GUI menus include the following basic structures:
GUI Menu architecture
Menu
Basic configuration menu/list
Sub-menu
Sub-menu
Menu
26
Position
Triggers a WLAN bandscan.
Displays the next page in a list.
Displays the previous page in a list.
Position
Here you can set the interval in which the view is to be updated.
To do this, enter a period in seconds in the input field and click on
.
You can have the list entries filtered and displayed according to certain criteria.
You can determine the number of entries displayed per page by entering the re-
quired number in View x per page.
Use the and buttons to move from one page to the next and back.
Using certain keywords within the configuration parameters, you can filter by se-
lecting the filter rule underFilter in x <Option> y and entering the search word in
the input field. launches filter operation.
Some lists contain configuration elements.
This means you can change the configuration of the corresponding list entry dir-
ectly in the list.
Position
When you select a menu from the navigation bar, the basic parameters menu is
displayed first. In a sub-menu made up of several pages, the menu containing the
basic parameters is displayed on the first page.
This contains a list of all the configured entries or the feature's basic settings.
Every menu that displays a list of all the configured entries has a New button.
Click on it to display the configuration menu needed to create a new list entry.
Click on this button to process the existing list entry. It takes you to the configura-
tion menu.
Click on this tab to display more configuration options.
