5 Technical data

Chapter 5 Technical data

This chapter summarizes all the hardware properties of the APR222ac device.

5.1 General Product Features

General product features cover performance aspects and the technical prerequisites for the installation and operation
of your device. The following table summarizes these features:
General Product Features
Property
Dimensions and weights:
Equipment dimensions without cable
(W x L x H)
Weight
Material
LEDs
Power consumption of the device
Voltage supply
Environmental requirements:
Ingress Protection Rating
Storage temperature
Room temperature
Relative atmospheric humidity
Available interfaces:
WLAN
Ethernet IEEE 802.3 LAN
Available sockets:
Ethernet interface
Antenna sockets
Power supply socket
Buttons
To ensure safe operation, APR222ac devices have a protective earth connection. The minimum cross-section of the
earth lead should be 2.5 mm². The distance between the device and the earth connection should be as short as pos-
sible.
14
Value
ca. 212 x 212 x 40 mm plus 30 mm mounting kit (2x15mm).
Approx. 2,600 g.
Paint-coated galvanized iron sheet.
4 (1x Power, 1x Status, 2x WLAN).
Max. 20 W.
Integrated power supply. Galvanic isolation, 110 V DC or 24 V
DC (depending on the model) -30 % + 25 % (power supply ac-
cording to EN 50 155, except for 10 ms power interruption at full
operation).
IP 30 (Solid particle protection >2.5mm).
-40 °C to +85 °C.
EN 50155 Class T3: -25...+70°C / +85°C 10 min.
EN 50155: annual average value <= 75 %, at 30 days per year 95
%.
2 x radio modules for 802.11 ac, 2.4GHz or 5GHz, 2x2 MIMO.
10/100/1000BaseT(X) M12 (8-pin).
2 x 8-pole female M12 socket.
Each radio has two female N-type antenna sockets (a total of four
antenna sockets).
ANT1 is internally connected to CH1 and ANT 2 is internally con-
nected to CH0 at radio module 1.
ANT3 is internally connected to CH1 and ANT 4 is internally con-
nected to CH0 at radio module 2.
4-pole male M12 socket.
Reset.
