Using a MobileView Terminal With Multiple IP20 Junction Boxes

Connection Diagrams

Figure 2 - MobileView Terminal Side
2711T Terminal
Main Connector
1
2
3
4
5
6
7
8
9
10
11
12
Communication
Interface
1
TD+
2
TD-
3
RD+
6
RD-
Operating Element
Interface
1
Ext1
2
Ext2
3
Ext3
4
Ext4
5
Reserved
8
Connection Cable
S2
Pink
Black
Brown
White-green
Gray
Red-blue
Green-brown
Yellow
Green
Gray-pink
S3
Blue
White
Orange
Red
S4
Violet
White-pink
White
Blue
White-blue
Rockwell Automation Publication 2711T-AT001B-EN-P - February 2017
IP20 Junction Box
S1 X4
1 1
+24V DC
2 2
GND
3 3
E-stop_ES2(+)
4 4
E-stop_ES2(-)
5 5
E-stop_ES1(+)
6 6
E-stop_ES1(-)
7 7
Enable_ED1(+)
8 8
Enable_ED1(-)
9 9
Enable_ED2(+)
10 10
Enable_ED2(-)
11 11
Not used
13 13
TD+
14 14
TD-
15 15
RD+
16 16
RD-
12 12
17 17
18 18
19 19
20 20
Field Wiring
X1
1
24V DC
2
GND_IN
5
E-stop, circuit 2 (+)
6
E-stop, circuit 2 (-)
3
E-stop, circuit 1 (+)
4
E-stop, circuit 1 (-)
7
Enabling device, circuit 1 (+)
8
Enabling device, circuit 1 (-)
9
Enabling device, circuit 2 (+)
10
Enabling device, circuit 2 (-)
11
X3
Ethernet
1
RD+
2
RD-
3
TD+
4
TD-
5
6
7
8
X2 Options
3-position keyswitch:
X2
1: Left position
1
2: Center position
3: Common
2
4: Right position
3
Illuminated (white LED)
4
push button:
1: Contact (N.O.)
5
2: 24V (0V) illumination
6
3: Common
4: 0V (24V) illumination
