Abbreviations

This publication uses the following abbreviations.
Abbr Description
DCM Dual channel input monitor
DCS Distributed control system
DCSRT Dual channel input start
DHCP Dynamic host configuration protocol
EOI Electronic operator interface
FP Fault presence
(1) When used with a number (for example, IP20), IP means International Protection or Ingress Protection.

General Safety Information

Contact Rockwell Automation to find out more about our safety risk assessment services.
IMPORTANT This application example is for advanced users who are trained and experienced in safety system requirements.
ATTENTION: Perform a risk assessment to make sure all task and hazard combinations have been identified and addressed. The
risk assessment can require additional circuitry to reduce the risk to a tolerable level. Safety circuits must take into consideration
safety distance calculations, which are not part of the scope of this document.

Introduction

This application technique explains how to wire, configure, and program a GuardLogix® controller and POINT Guard
I/O™ module so a single MobileView™ terminal
controlled safety areas.
For partial-body access applications with slow machine speed, the operator can energize the motors by squeezing the
MobileView terminal enabling switch to the middle position after the safety door interlock access has been performed.
Safety door interlock management is not covered in this publication.
Follow the procedures described in this publication to use a bypass switch (formerly a two-position key lock switch) as a
plug for the MobileView junction box.
In this publication, the application examples use a Compact GuardLogix controller, but the information also applies to
any safety ControlLogix® controller.
IMPORTANT The application examples in this publication apply only to the following:
• A MobileView terminal with an integrated enabling switch and gray stop push button, but not to any MobileView terminal
with an emergency stop (E-stop) push button
• A MobileView IP20 junction box, but not to any MobileView IP65 junction box
(1) Applies only to MobileView terminals with gray stop button, cat. nos. 2711T-F10G1N1 and 2711T-T10G1N1.
Abbr Description
I/O Input/output
(1)
IP Internet protocol
JB Junction box
N.C. Normally closed
N.O. Normally open
PC Personal computer
(1)
can be used with multiple MobileView IP20 junction boxes in
Rockwell Automation Publication 2711T-AT001B-EN-P - February 2017
