Using a MobileView Terminal With Multiple IP20 Junction Boxes
Connection Layout POINT I/O
Figure 3 - 1734-IB8S Field Connections
I0 I1 I4
0 1
I2 I3 I6
2 3
COM COM COM
4 5
TO T1M T2
6 7
1734-TOP and 1734-TB Bases Shown
Where:
TO = Test output 0
T1M = Test output 1 with muting
T2 = Test output 2
T3M = Test output 3 with muting
I0...I7 = Inputs 0...7
COM = Supply common
Table 5 - Pinouts for MobileView Terminal, 1734-IB8S, Bypass Switch, and Push Button
MobileView Terminal
Pin Signal
1 24V DC
2 GND_IN
3 E-stop, circuit 1 (+)
4 E-stop, circuit 1 (–)
5 E-stop, circuit 2 (+)
6 E-stop, circuit 2 (–)
7 Enabling device, circuit 1 (+)
8 Enabling device, circuit 1 (–)
9 Enabling device, circuit 2 (+)
10 Enabling device, circuit 2 (–)
Key Selector (safety)
Pin Signal
1 Normally closed (N.C.)
2 N.C.
N/A
1 Normally open (N.O.)
2 N.O.
E-stop Push Button (800F)
Pin Signal
1 N.C.
2 N.C.
N/A
1 N.O.
2 N.O.
Reset Push Button (800F)
Pin Signal
1 N.C.
N/A
2 N.C.
(1) Push button is near MobileView junction box.
10
Figure 3 - 1734-OB8S Field Connections
I5 00
0 1
I7 02
2 3
COM COM
4 5
T3M COM
6 7
1734-TOP and 1734-TB Bases Shown
Where:
O0...O7 = Safety outputs 0...7
COM = Supply common
1734-IB8S
Cable Color Pin Signal
Red (power)
Black (power)
Brown 6 T0 Test output
Blue 0 I0 E-stop, circuit 1
White/brown 7 T1M Test output with muting
White/blue 1 I1 E-stop, circuit 2
Green 6 T0 Test output
White/orange 2 I2 Enabling device, circuit 1
Green/white 7 T1M Test output with muting
Orange 3 I3 Enabling device, circuit 2
1734-IB8S
Cable Color Pin Signal
Blue 6 T2 Test output
Orange 0 I4 Auxiliary contact, N.C. (800F)
White/blue 7 T3M Test output
White/orange 1 I5 Auxiliary contact, N.O. (800F)
(1)
1734-IB8S
Cable Color Pin Signal
Red 6 T2 Test output
White 2 I6 Circuit 1, N.C., 800F E-stop
Black 7 T3M Test output
Yellow 3 I7 Circuit 2, N.C., 800F E-stop
(1)
1734-IB8S
Cable Color Pin Signal
White 0 I0
Green 6 V
