Additional Resources - Rockwell Automation Allen-Bradley MobileView Terminal Application Technique

5. Disconnect the MobileView connection cable from junction box in Area 3.
IMPORTANT When the MobileView terminal is not plugged into a junction box, the MobileView terminal must be stored where it is
not visible to operators.
Application 3: The Junction Boxes Are in Hazardous and Non-hazardous Areas
If a MobileView terminal must be connected to and removed from a junction box in a hazardous area, then follow all
steps in Application 1: All Junction Boxes Are in a Hazardous
If a MobileView terminal must be connected to and removed from a junction box in a non-hazardous area, then follow all
steps in Application 2: All Junction Boxes Are in a Non-hazardous
IMPORTANT When the MobileView terminal is not plugged into a junction box, the MobileView terminal must be stored where it is not
visible to operators.

Additional Resources

These documents contain additional information about related products from Rockwell Automation.
Resource
Compact GuardLogix 5370 Controllers User Manual, publication
GuardLogix Controllers User Manual, publication
MobileView Tethered Operator Terminal User Manual, publication
FactoryTalk View Machine Edition User's Guide, publication
POINT Guard I/O Safety Modules User Manual, publication
GuardLogix Controller Systems Safety Reference Manual, publication
GuardLogix Safety Application Instruction Set Reference Manual, publication
1756-RM095
Safety Accelerator Toolkit for GuardLogix Systems Quick Start Guide, publication
IASIMP- QS005
Industrial Automation Wiring and Grounding Guidelines, publication
Rockwell Automation Safety Products Catalog, available from the Product Catalogs link at
http://www.ab.com
You can view or download publications at http://www.rockwellautomation.com/literature/. To order paper copies of
technical documentation, contact your local Allen-Bradley distributor or Rockwell Automation sales representative.
1769-UM022
1756-UM020
2711T-UM001
VIEWME-UM004
1734-UM013
1756-RM093
1770-4.1
Rockwell Automation Publication 2711T-AT001B-EN-P - February 2017
Using a MobileView Terminal With Multiple IP20 Junction Boxes
Area, which starts on page
Area, which starts on
Description
Provides information on how to configure, operate, and maintain Compact
GuardLogix controllers.
Provides information on how to configure, operate, and maintain GuardLogix
controllers.
Provides information to install, operate, and troubleshoot the MobileView 2711T
terminal.
Provides comprehensive information about FactoryTalk View Machine Edition,
procedures to create and run an automation application, and reference information.
Provides information on how to install, configure, and operate POINT Guard I/O
modules.
Contains detailed requirements for how to achieve and maintain safety ratings with
the GuardLogix controller system in an RSLogix 5000® project.
Provides detailed information on the GuardLogix Safety Application Instruction Set.
Provides a step-by-step guide on how to use the design, programming, and
diagnostic tools in the Safety Accelerator Toolkit.
Provides general guidelines on how to install a Rockwell Automation® industrial
system.
Provides information on safety products available from Rockwell Automation.
14.
page 16.
17
