function. Enable means before the remote converter power off, the
remote converter will send out the alarm notice to the central manager
converter
3. In-Band Loop Back Test: Checking the fiber port connection
status between remote and central site converter. User needs to set a
transfer value, and verify the return value is for verifying if the value
the same as user has set
4. Auto Loop Back Test: Checking the fiber port connection status
between remote and central site converter automatically
5. Bandwidth rate control & Terminal Tx port Config: Bandwidth
rate control terminal UTP port
6. Terminal Tx port Table (Read only): Displaying the terminal UTP
port table information
8. Auto Polling: Set the value as 'True' to enable auto polling. When Auto
Polling is set as 'True', the management board then is able to
communicate with the particular module.
Q. Quit: Exit from the current interface

Redundant Power Status

It shows current power supply status. The device has two slots for Power
20
