Configuration

Go to Monitor
Threshold, Alarm Threshold, Title and Type. Please note that you can use the
two dip switches to set different operation modes. Please see the table below
for detail information.
http://192.168.1.100/
Dip 1 Dip 2
OFF OFF
OFF ON
ON OFF
ON ON

Environment
Opeation
Mode
The SNMP IPv6 works with the UPS. It provides the
Normal Mode UPS's status information and parameters through
a network system.
The SNMP IPv6 stops polling the UPS but transfers
Pass Through
the communication data between the console
Mode
port and the UPS.
The SNMP IPv6 works with the UPS and an option-
Sensor Mode
al EnviroProbe. It provides the UPS's information
(with
and the environmental parameters (temperature,
EnviroProbe)
humidity, etc).
In this mode, the user can login through the con-
Configuration sole port and configure the SNMP IPv6's settings.
Mode Please refer to 4-4 Configuring through COM
Port.
Configuration to configure the Warning
Description
