SNMP IPv6 for UPS
Step 2 Find the two grooves inside the external SNMP box (see Figure 3-f).
Figure 3-f
Two grooves
Step 3 Insert the SNMP IPv6 into the grooves (see Figure 3-g).
Figure 3-g
Two grooves
Step 4 There are three covers provided in the SNMP IPv6's package. Please
follow the location of screw holes on the external SNMP box to select
the suitable cover, and use the two screws that you just removed to
fix the cover on the external SNMP box (see Figure 3-h).
Figure 3-h
