- Page 1 CC612 EV charge controller Charge controller for electric vehicle charging stations, wall boxes and street light charging points CC612(4G)_D00325_05_Q_XXEN / 10.2019 Quickstart EN...
-
Page 2: Intended Use
CC612 EV charge controller Information! Read the corresponding manual in addition to this quickstart. Downloadable at: www.bender.de/en/service-support/downloads Type of device Modem Meter RDC-MD* PLC** User LEDs Art. No. hardware interface CC612 -1M4PR eHZ, S0 ü ü ü Ready, B94060011 interface... -
Page 3: Dimensions And Installation
CC612 EV charge controller Dimensions and installation 115,13 22,60 CC612 ALARM READY Note: All dimensions are in mm and are according to ISO 2768-m. CC612(4G)_D00325_05_Q_XXEN / 10.2019... - Page 4 Connection ! Risk of electric shock! anger Parts of the system can be energised (the charge controller terminals up to 12 V, the charging system voltage is 230 V). Before touching live parts of the system, ensure that the installation has been de-energised.
-
Page 5: Terminal Assignment
CC612 EV charge controller Legend Connector Current Transformer (CT) Contactor Connector User Interface Type 2 socket* Connector Type 2 plug* Connection Current Transformer (CT) Control pin (contactor) Connection User Interface (RJ45) PLC (optional) via this terminal Connection Modbus/eHZ meter (RJ10) - Page 6 Unlocking the CT plug ! Risk of damage when pulling out the CT plug! aution If the CT plug is pulled out using too much force, the enclosure and the internal components may be damaged. Use needle-nose pliers to unlock the CT plug. Connection Type 2 Socket Supported Type 2 sockets* –...
-
Page 7: Technical Data
CC612 EV charge controller Technical Data Insulation coordination acc. to IEC 60664-1/IEC 60664-3 Rated voltage ....................................12.5 V Overvoltage category/Pollution degree .............................III/3 Rated impulse withstand voltage..............................800 V Altitude...................................≤ 2,000 m AMSL Supply voltage Nominal voltage.....................................DC 12 V Operating range of the supply voltage..........................DC 11.4…12.6 V Nominal current ....................................1 A... - Page 8 Connection Connection cable....................................RJ45 Maximum length connection cable..............................< 3 m Connection type (terminal block C)......................Push-wire terminal Connection properties: rigid/flexible.............................0.2…1.5 mm² (AWG 24…16) flexible with ferrule without plastic sleeve....................0.25…1.5 mm² (AWG 24…16) flexible with ferrule with plastic sleeve....................0.25…0.75 mm² (AWG 24…20) Stripping length....................................10 mm Opening force..................................0.5…0.6 Nm Connection type (terminal blocks A and B)....................screw-type terminal Connection properties:...
-
Page 9: Ec Declaration Of Conformity
CC612 EV charge controller EC Declaration of Conformity Bender GmbH & Co. KG Postfach 1161 • 35301 Grünberg/Germany Londorfer Straße 65 • 35305 Grünberg/Germany Phone: +49 6401 807-0 • Fax: +49 6401 807-259 E-Mail: info@bender.de • www.bender.de EU - K o n f o r m i t ä t s e r k l ä r u n g... - Page 10 CC612(4G)_D00325_05_Q_XXEN / 10.2019...
- Page 11 CC612 EV charge controller CC612(4G)_D00325_05_Q_XXEN / 10.2019...
- Page 12 Nachdruck und Vervielfältigung Reprinting and duplicating nur mit Genehmigung des Herausgebers. only with permission of the publisher. Bender GmbH & Co. KG Bender GmbH & Co. KG Postfach 1161 • 35301 Grünberg • Deutschland PO Box 1161 • 35301 Gruenberg • Germany Londorfer Str.
