SimCom SIM68R Hardware Design page 13

Table of Contents

Advertisement

V_OUT
8
VCC_RF
18
V_ANT
19
V_BACKUP
11
GND
7,13,14,15,17
Host port interface
SDA
1
SCL
2
TXD
3
RXD
4
TXD1
22
RXD1
21
GPIOs
EINT0
27
TIMEMARK
28
NRESET
10
DET_N
20
RF interface
RF_IN
16
Other interface
5,12,23,24,25
NC
,26
Reserved
9
SIM68R_Hardware Design_V1.02
Output voltage. It Has been connected
O
to VCC inside the Module
2.8V output power supply for active
O
antenna
I
Antenna Bias voltage
The backup battery input power supply
I
for RTC
Ground
2
I/O
I
C data
2
I/O
I
C C Clock
O
Serial output
I
Serial input
O
Serial output as RTCM
I
Serial input as RTCM
This interrupt source could act as wake
up event during power saving mode.
I
Provide an interrupt on either high or
low
logic
level
interrupt
Time Mark outputs timing pulse related
O
to receiver time
I
Reset input, active low
I
Active Antenna Detect
I
Radio antenna connection
Not Connected
Not Connected
13
Smart Machine Smart Decision
If unused, keep open.
If unused, keep open.
If unused , connect to
GND
If unused, keep open.
GND
If unused, keep open.
If unused, keep open
If unused, keep open
Not supported yet, keep
open.
or
edge-sensitive
If unused, keep open.
If unused, keep open.
If unused, keep open.
Impendence
controlled to 50Ω.
must
be
2013-01-22
