Specifications; Dimensions - intervolt DCC Pro Installation & Operation Manual

Input Voltage
Main
Solar
Solar Power
Continuous Rating
Current Draw
Charging Device
Remote Display
Output Voltage
Standard Lead Acid
Absorbed Glass Mat
Gelified Electrolyte
Lead Calcium
LiFePO4 BMS
Electrical Protection
Environmental Protection
Charging Device
Remote Display
Operating Temperature
Operating Humidity
Charging Device Materials
Heatsink
Blue Plastics
Black Plastics
Transparent Plastics
Remote Display Materials
Dark Grey Plastics
Transparent Plastics
Termination
Conformity

Dimensions

Charging Device
Remote Display
Weight
Charging Device
Remote Display
36
9 – 16 VDC
18 – 28 VOC (open circuit Voltage – no load)
Unrestricted (system limited to 25 Amps)
25 Amps@50°C (de-rate from 50°C to 85°C)
In stand by: Including LED indicator <10mA
At full load: Up to 35 Amps
With backlight off: 10mA max
With backlight on: 45mA max
Boost/CC Absorption/CV
14.5 VDC 14.4 VDC
14.7 VDC 14.6 VDC
14.3 VDC 14.2 VDC
14.9 VDC
14.8 VDC
14.6 VDC
Voltage values subject to tolerance ± 0.1V
Over temperature disconnect – auto re-connect
Under Voltage shutdown – auto re-start
High Voltage disconnect – auto re-connect
Reverse polarity protection on all terminals
IP67 (internal components only)
IP40 (not dust or water resistant)
-20°C to +85°C
Up to 100% (non-condensing)
E-Coated ADC-3 die cast aluminium
10% glass reinforced PC/ABS alloy
15% glass reinforced PBT
Temperature resistant PMMA
Temperature resistant PC/ABS alloy
Temperature resistant PMMA
Tin plated brass terminals, 304SS fasteners
AS/NZS CISPR 11:2004 for EMC
112 x 112 x 75mm (including terminal cover)
60 x 36 x 59mm (including mounting bracket)
690 grams
55 grams
Float/CV
13.4 VDC
13.6 VDC
13.5 VDC
13.8 VDC
14.4 VDC
