intervolt DCC Pro Installation & Operation Manual page 30

OK
OK
g.i
OK
The Battery Icon is a useful quick reference tool used to indicate the charging
cycle status, when the Remote Display is in dual Voltage mode for example.
28
Backlight On/O Control
By default the backlight is always on when powered but it
can be switched o at any time by pressing and holding
the button for 2 seconds. It can be switched on again
by pushing either the
Toggle Alternate Screen
By default, the lower three digit character set will display
the current in Amps or, if solar power is in use, the
charging power in Watts (see g. i). The multi-function
character set will display the charging source and the
charge stage. Pressing the
toggle an alternate screen to display the main battery
voltage on the lower character set and the battery type
on the multi-function set (see g. ii).
g.ii
Toggle Between Two Charging Devices
If two Charging Devices are installed and connected to
a single display it is easy to toggle between both by
momentarily pressing the
will indicate the status of the device being monitored. If
only one device is connected the
appear and pressing the
error message. The message will clear after a few seconds.
Boost/CC charging – All bars are continuously lling up in a cycle.
Absorption/CV charging – The rst three bars are lled and
steady and the last one is lling up.
Float/CV charging – All bars are lled and steady.
or button momentarily.
button momentarily will
OK
button. The
AB
or icons will not
button will result in a system
AB
or icon
