Input Voltage
Main
Solar
Solar Power
Continuous Rating
Current Draw
Charging Device
Remote Display
Boost Voltage
Standard Lead Acid
Absorbed Glass Mat
Gelified Electrolyte
Lead Calcium
Float Voltage
Electrical Protection
Environmental Protection
Charging Device
Remote Display
Operating Temperature
Operating Humidity
Charging Device Materials
Heatsink
Blue Plastics
Black Plastics
Transparent Plastics
Remote Display Materials
Dark Grey Plastics
Transparent Plastics
Terminal Material
Terminal Fasteners
Conformity
Dimensions
Charging Device
Remote Display
Weight
Charging Device
Remote Display
34
9 – 17 VDC
27 VOC max. (open circuit – no load)
250 Watts nominal (300 Watts peak)
25 Amps @ 50°C
Including LED indicator <10mA (in standby)
With backlight off: 10mA max
With backlight on: 30mA max
14.4 VDC Nominal
14.6 VDC Nominal
14.2 VDC Nominal
14.8 VDC Nominal
13.2 VDC Nominal
Thermal overload shutdown – auto reset
Electrical overload shutdown – auto reset
Under voltage disconnect – auto re-connect
Over voltage disconnect – auto re-connect
Reverse polarity protection of main terminals
IP67 (internal components only)
IP40 (not dust or water resistant)
-20°C to +85°C
Up to 98%
E-Coated ADC-3 die cast aluminium
Temperature resistant PC/ABS alloy
15% glass reinforced PBT
Temperature resistant PMMA
Temperature resistant PC/ABS alloy
Temperature resistant PMMA
Tin plated brass
304 stainless steel
AS/NZS CISPR 11:2004 for EMC
112 x 112 x 75mm (including terminal cover)
60 x 36 x 59mm (including mounting bracket)
690 grams
55 grams
