INTRODUCTION

Introduction
This book contains all the necessary fitting and
operating instructions for your Triton Spellbind
thermostatic electric shower. Please read them
carefully.
The shower installation must be carried out by a
suitably qualified person and in the sequence of
this instruction book.
Care taken during the installation will ensure a
long, trouble-free life from your shower.

SPECIFICATIONS

Specifications
Electrical
Nominal power
rating at 240V
9.5kW – (40A MCB rating) 8.7kW – (40A MCB rating)
10.5kW– (45A MCB rating) 9.6kW – (45A MCB rating)
Water
Inlet connection – 15 mm diameter.
Outlet connection – ½" BSP male thread.
Entry Points
Water – Right: middle back, bottom, top.
Cable – Right: middle back, bottom, top.
Materials
Backplate, cover, controls, showerhead – ABS.
Sprayplate – Acetal.
Elements – Minerally insulated corrosion resistant
metal sheathing.
Dimensions
Height – 335 mm
Width – 225 mm
Depth – 95 mm
Standards and Approvals
Splashproof rating IPX4.
Complies with the requirements of current British
and European safety standards for household
and similar electrical appliances.
Complies with requirements of the British
Electrotechnical Approvals Board (BEAB).
Meets with Compliance with European
Community Directives (CE).
Replacement parts can be ordered from Customer
Y-003-A
Service. See 'spare parts' for details and part numbers.
Spellbind
Nominal power
rating at 230V

UNDERSTANDING YOUR SHOWER

Understanding your shower
IMPORTANT: When first installed the unit
will be empty. It is essential the unit should
contain water before the elements are
switched on.
I-001-A
commissioning
Failure to carry out this operation will result
in damage to the unit and will invalidate the
guarantee.
Temperature/flow rate
The temperature control on the unit can be
adjusted to provide shower temperatures
nominally between 35°C and 47°C. The unit
will give higher and lower temperatures if given
extreme supply conditions.
Note: The maximum flow rate for the given
temperature will be greater in the summer
than in winter because of ambient temperature
variance of the mains water supply.
It is strongly advised to select economy power
during periods of hot weather, otherwise at all
other times leave the power setting at full to
provide the maximum flow rate.
Safety cut-out
The unit is fitted with a non-resettable over-
temperature safety device. In the event of
abnormal operation which could cause unsafe
temperatures within the unit, the device will
disconnect the heating elements. It will require a
visit from a qualified engineer to determine the
nature of the fault and replace the safety device,
once the unit has been repaired.
2
It is vital that
procedure is followed.
the
