Spellbind
It will take about thirty seconds for a smooth
Fig.19
flow of water to be obtained while air and any
debris is being dispersed from the shower. When
a smooth flow of water is obtained, disconnect
the electricity supply to the shower at the
isolating switch. This will stop the water flow.
Unscrew the cover retaining screws again and lift
the cover from the backplate.
Attached to the control PCB, inside the cover,
is a 14-way ribbon cable. The ribbon cable
connector must be plugged into the socket
located on the power PCB situated inside the
unit (fig.19). The connector can only be
correctly plugged in one way by virtue of a
location lug on the plug. The ribbon cable also
has a coloured edge which is on the right-hand
side when correctly fitted to the socket.
15
