- Page 1 Safeguard Safeguard T100 Care electric shower Installation and operating instructions nstallers please note these InstructIons are to be left wIth the user 2180653Q September 2008...
-
Page 2: Table Of Contents
In-service Testing (Safeguard T100 Care only) ......29 - 33 Service policy ................. 37 Guarantee, etc................. rear cover To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Telephone: 0870 067 3767... -
Page 3: Important Safety Information
PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. WARNING: DO NOT operate shower if frozen, or suspected of being frozen. - Page 4 3.4 Make sure all electrical connections are fitted. For advice on the Triton Scale Inhibitor, tight to prevent overheating. contact Triton Customer Service. 3.5 Fuses do not give personal protection 1.8 The showerhead must be cleaned regularly against electric shock. with descalent to remove scale and debris, 3.6 A 30mA residual current device (RCD)
-
Page 5: Introduction
Advice to Users This book contains all the necessary fitting and IMPORTANT: When first installed the unit operating instructions for your Triton Safeguard will be empty. It is essential the unit should and Safeguard T100 Care electric shower. contain water before the elements are Take time to read this book thoroughly and switched on. -
Page 6: Main Components
main Components Inside the unit (fig.1) note: Wires have not been shown for reasons of clarity. Inside the unit (fig.1) 1. Top cable/pipe entry 6. Can and element assembly 11. Solenoid valve . Wall screw fixings 7. Flow switch assembly 1. - Page 7 Components (continued) Inside cover (fig.) Inside cover (fig.) 16. Stop/start switch 17. Control printed circuit board Other items Screw fixing kit Instructions, guarantee, etc. Safeguard T100 Care cover Safeguard cover...
-
Page 8: Electrical Requirements
Electrical Requirements Fig. WARnInG! THIS APPLIAnCE mUST BE EARTHED Shepperton Park, Triton Road, Nuneaton, Warwickshire, CV11 4NR The installation, supply cable and circuit protection must conform with BS 7671 (IEE wiring regulations) and be sufficient for the amperage required. The following notes are for guidance only: The shower must only be connected to a 230-240V ac supply. - Page 9 be installed in all UK electric and pumped 6.2 The switch must be accessible and clearly shower circuits. This may be part of the identifiable, but out of reach of a person consumer unit or a separate unit. using a fixed bath or shower, except for the Table A A 45 amp double pole isolating switch with cord of a cord operated switch, and should...
-
Page 10: How To Operate The Shower
HOW TO OPERATE THE SHOWER When the electricity supply Fig.A to the shower is switched on at the isolating switch, the power indicator will Power On indicator light. Low Flow indicator To start the shower Timed Shutdown Press the start/stop bar and indicator water will flow. - Page 11 *To stop the shower WARnInG! (timed Shutdown) This appliance is not Shutdown times can be intended for use by set at 5, 10, 0 (factory persons (including setting) or 0 minutes. children) with reduced When the indicator physical, sensory or illuminates it indicates there mental capabilities, is 1 minute before the...
- Page 12 Adjusting the temperature note: In normal use, control can alter the flow of it is in order to leave water through the unit. the water supply After obtaining your permanently on to preferred showering the shower unit, but temperature the number as with most electrical setting can be appliances, the unit...
- Page 13 When the start/stop bar is WARnInG! pressed water will continue Before normal to flow in order to remove operation of the heated water inside the shower, it is essential unit (see phased shutdown the commissioning process). Water will cease to procedure is completed flow after a few seconds.
-
Page 14: Water Requirements
Water Requirements The installation must be in accordance with Water Regulations/Bylaws. Supply Source ..........Mains pressure cold water only Minimum running pressure ...... 50kPa (0.5 bar) at 8 litres per minute* and flow at the shower inlet* Maximum static pressure ......1000 kPa (10 bar) Maximum inlet temperature ...... -
Page 15: Siting Of The Shower
Siting of The Shower WARnInG! For ease of servicing, the unit must always be The shower must not be positioned mounted on the surface of tiled walls. Never where it will be subjected to freezing tile up to the unit. conditions. -
Page 16: Fitting The Shower To The Wall
Fitting the Shower to the Wall Fig.7 note: The control knobs are an integral part of the cover – DO NOT attempt to remove them. Unscrew the two top and one bottom retaining screws (fig.7) and lift the cover from the backplate. -
Page 17: Plumbing Connections
Plumbing Connections Fig.10 Plumbing to be carried out before wiring DO NOT use jointing compounds on any pipe fittings for the installation. DO NOT solder fittings near the shower unit as heat can travel along pipework and damage components. Compression fittings MUST be used to connect 21 mm to the inlet of the shower. - Page 18 Fig.11 The Inlet fitting is designed to rotate through to allow for either Top or Bottom/Rear entry fitting (fig.11). note: The inlet fitting is designed to enter a compression fitting only. DO NOT use push fit connectors as full engagement cannot be guaranteed.
-
Page 19: Electrical Connections
Electrical Connections Fig.1 SWITCH OFF THE ElECTRICITy SUPPly AT THE MAINS. Fig.1 shows a schematic wiring diagram. The cable entry points are shown in fig.1. The cable can be surface clipped, hidden or via 20 mm conduit. note: Conduit entry can only be from rear. Route the cable into the shower unit and connect to the terminal block (fig.1) as follows: Earth cable to terminal marked... -
Page 20: Whale Pump (Not Supplied)
NOTE: leave 20cm of the double insulated cable (as supplied in Whale kit) exposed from the wall to allow connection to the 2 way connector on the Triton Safeguard circuit board. This connection is not polarity sensitive. Complete the connection by joining the other end of the double insulated wire to the bell wire (cut bell wire to suit) from the transformer. -
Page 21: Commissioning
PCB fitted in the shower (fig.15). Adjusting the maximum temperature stop (Safeguard T100 Care only) The temperature control valve has an adjustable maximum temperature stop mechanism that is supplied factory set for 41°C. - Page 22 Note: Removal of power to the PCB is the only way to exit the Commissioning Mode. NOTE: IF COMISSIONING THE SAFEGUARD T100 CARE, PlEASE REFER TO PAGES 29 - 33 AND MAKE SURE THAT THE APPROPRIATE SECTIONS ARE COMPlETED.
-
Page 23: Pcb Dip Switch Settings
DIP Switch Settings Fig.19 A four way DIP switch block is mounted on the control PCB that allows the user to configure the shower to perform different functions (fig.19). 1 2 3 4 DIP SWITCH no. OPERATIOn EnABLED SWITCH POSITIOn DIP switch 1 On AUDIBLE FEEDBACK On (Factory setting) -
Page 24: Replacing The Cover
Replacing the Cover Fig.0 Attached to the display PCB, inside the cover, is a 10-way ribbon cable. The ribbon cable connector must be plugged into the socket located at the right of the power PCB situated inside the unit (fig.0). note: The cable connector can be fitted to the socket only one way. -
Page 25: Operating Functions
OPERATInG FUnCTIOnS Fig.1 (fig.1) Power on indicator (green) When the electricity supply to the shower is switched on at the isolating switch, the power Power On indicator indicator will light up. Low flow indicator (red) Low Flow indicator If a low flow condition occurs the unit will turn off the water flow immediately. -
Page 26: Instructions For Installers And Service Engineers Only
INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only Cleaning the Filter Fig. It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower. It is essential that this operation is carried out by a competent person. -
Page 27: Spare Parts
SPARE PARTS Ref. Description Part no. Top and bottom pipe entry trim 83312720 Thermal safety cut-out 22012020 Power printed circuit board 7073709 Can and element assembly 83313080 Flow switch assembly P19521004 Temperature Control assembly S19520805 Terminal block and wires S19520901 Solenoid valve assembly P19520800 Water inlet filter assembly... - Page 28 Triac and wires (not shown) P19520903 Thermister (not shown) 22012030 1. Front cover pcb 7073708 15. Safeguard T100 Care front cover assembly S19520601 (includes pcb and start/stop switch) 16 . Safeguard Front cover assembly S19520602 (includes pcb and start/stop switch)
-
Page 29: Fault Finding
FAULT FInDInG FAULT FINDING IMPORTANT: Switch off the electricity at the mains supply and remove the circuit fuse before attempting any fault finding inside the unit. Problem/Symptom Cause Action/Cure Problem/Symptom Cause Action/Cure 1 Shower inoperable, no 1.1 Interrupted power 1.1.1 Blown fuse or circuit breaker. - Page 30 FAULT FINDING FAULT FInDInG Problem/Symptom Problem/Symptom Cause Cause Action/Cure Action/Cure 6 Low flow LED 6.1 Low flow condition 6.1.1 Insufficient water flow available. permanently on when 1. Check showerhead is not blocked start/stop bar pressed. 2. Check shower hose is not restricted. Shower will not start.
-
Page 31: In-Service Testing (Safeguard T100 Care Only)
- Safeguard T100 Care OnLy In-SERVICE TESTInG (Safeguard T100 Care only) Designation Code: -IW-S Shower... - Page 32 - Safeguard T100 Care OnLy...
- Page 33 - Safeguard T100 Care OnLy...
- Page 34 - Safeguard T100 Care OnLy nOTES FOR COmmISSIOnInG AnD In-SERVICE TESTInG 1. measuring the Shower Outlet Water . measurement of Supply Voltage at Temperature Appliance Terminals With the shower running, position the Switch off the electricity at the mains supply showerhead horizontally and place a funnel and remove the circuit fuse.
- Page 35 - Safeguard T100 Care OnLy FREqUEnCy OF In-SERVICE TESTInG Table 1 Conditions for In-service test Next in-service test 6 to 8 weeks after First in-service test. commissioning. If no significant change in water outlet temperature 12 months after (greater than ±1°C) between commissioning and first test.
-
Page 39: Service Policy
3 All products attended to by a Triton service engineer must be installed in full accordance with the Triton installation guide applicable to the product. (Every product pack contains an installation guide, however, they can also be bought via our Customer Service Spares Department). - Page 40 Triton is a division of Norcros Group (Holdings) Limited e mail: technical@tritonshowers.co.uk Extended Warranty AVAILABLE NOW. Call 0870 067 3333 for more details. TRITON reserve the right to change product specification without prior notice. E&OA. © TRITON SHOWERS 2008...
