DF4900
BOX CONTENTS
A
B
C
D
LH UPRIGHT
RH UPRIGHT
LH REAR SUPPORT
RH REAR SUPPORT
QTY 1
QTY 1
QTY 1
QTY 1
E
H
F
G
LH FOOT
RH FOOT
CROSSMEMBER
TOP FRAME
QTY 1
QTY 1
QTY 1
QTY 1
I
WEIGHT PLATE HOLDER
QTY 4
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533
