DF9500
FLAT/INCLINE/DECLINE BENCH
Assembly Manual
Assembly Video Available
Simply scan the QR code below
on your phone's camera to access
the video
(888) 258-0533
FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533

Advertisement

loading
Need help?

Need help?

Do you have a question about the DF9500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Deltech Fitness DF9500

Summary of Contents for Deltech Fitness DF9500

  • Page 1 Simply scan the QR code below on your phone’s camera to access the video (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...

  • Page 2: Box Contents

    LEG PAD TUBE BACKREST SEAT SUPPORT SLIDE ASSEMBLY HARDWARE PACK SUPPORT QTY 1 QTY 1 QTY 1 QTY 1 QTY 1 *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 3 LOCK KNOB PULL-PIN QTY 2 QTY 4 QTY 1 QTY 1 (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 4 SEAT & BACKREST ASSEMBLY NOTE: THE SEAM GOES TO THE BOTTOM SIDE TOOLS REQUIRED: METRIC WRENCHES OR SOCKET SET Some components may be pre-installed from the factory ATTACH THE SEAT (F) TO THE SEAT SUPPORT (J) USING THE M10 x 25MM BOLTS (P) AND M10 FLAT WASHERS (R).

  • Page 5: Frame Assembly

    FRAME ASSEMBLY INSTALL THE PULL-PIN (U) AND LOCKING KNOB (V) INTO SLIDE ASSEMBLY (I). INSTALL THE SLIDE ASSEMBLY (I) ONTO THE FRAME (G). LOCK INTO PLACE WITH PULL-PIN. INSTALL PULL-PIN (U) INTO FRAME (G). ATTACH THE REAR FOOT (C) TO THE FRAME USING THE M10 x 25MM BOLTS (P) AND M10 FLAT WASHERS (R).

  • Page 6: Backrest Installation

    BACKREST INSTALLATION BACKREST ASSEMBLY ATTACH THE BOTTOM OF THE BACKREST ASSEMBLY TO THE FRAME USING M12 x 76MM BOLT (M), M12 FLAT WASHERS (Q), AND M12 LOCK NUT (S). NOW ATTACH THE BACKREST ASSEMBLY TO THE TOP OF THE BACKREST SUPPORT (K) USING M12 x 76MM BOLT (M), M12 WASHERS (Q), AND M12 NUT (S).
  • Page 7 LEG HOLD DOWN & SEAT INSTALLATION SEAT ASSEMBLY ATTACH THE SEAT ASSEMBLY TO THE FRAME (G) USING M12 x 76MM BOLT (O), M12 FLAT WASHERS (S), AND M12 LOCK NUT (U). (* NOTE THE TIGHTER YOU MAKE THE BOLT, THE MORE SECURE THE BENCH WILL BE.) INSERT THE LEG HOLD DOWN (D) INTO THE FRAME ASSEMBLY AND SECURE IT WITH THE PULL PIN.
  • Page 8 LEG HOLD DOWN ASSEMBLY INSERT THE LEG PAD TUBE (L)THROUGH THE HOLD DOWN (D). NOW SLIDE THE LEG PADS (E) ONTO THE LEG PAD TUBE. INSTALL MUSHROOM CAPS (X) INTO EACH END OF LEG PAD TUBE AND HAMMER INTO PLACE WITH RUBBER MALLET. ADJUST SEAT TO DESIRED ANGLE AND INSERT SEAT SUPPORT PIN (T).
  • Page 9 ADJUSTMENT ADJUSTING THE BACK PAD: RAISE AND LOWER THE BACKREST USING THE PULL PIN. MAKE SURE THE PULL PIN IS SECURE IN THE ADJUSTMENT HOLE AND THE KNOB IS TIGHTENED BEFORE USE. ADJUSTING THE SEAT PAD: RAISE THE SEAT PAD TO THE DESIRED POSITION BY USING THE PULL PIN THOUGH THE HOLES IN THE BRACKET.

  • Page 10: Safety Notice

    SAFETY NOTICE WARNING: THE USER OF THIS WEIGHT EQUIPMENT ASSUMES THE POSSIBILITY OF INJURY BY EXERCISING ON THIS EQUIPMENT. THE RISK OF INJURY CAN BE REDUCED BY ALWAYS FOLLOWING THESE SIMPLE RULES: 1) BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR DOCTOR FOR A COMPLETE PHYSICAL EXAMINATION AND SUGGESTED EXERCISE PROGRAM SPECIFIC FOR YOU.
  • Page 11 WEIGHT BENCH ACCESSORIES DF106 Add leg extension and leg curls to your bench with this leg attachment. Get more information at www.fitnessdestination.com DF105 Add preacher curls to your bench with this preacher curl attachment. Get more information at www.fitnessdestination.com DF1200 Add lat pulls to your bench with this lat attachment.
