Kolver EDU 2AE/TOP Manual page 8

- - - - - M E N U - - P R : 1 - - - - -
2 1 ) C o m p e n s : +
2 2 ) U n i t :
2 3 ) T o r q m i n :
21) Compens – Compensation:
after calibration. The available range is from 0 to ±9,99Nm. For example: after calibration (see Torque
calibration) you make a screwing cycle on your assembly and compare the value you see on the main
screen display with the value you see on a torque tester (for example a mini-K model). Let's say you notice
that the torque displayed in the unit EDU 2AE/HP is +0.2Nm higher than the value indicated on the tester
(which is the right one). In this case you change this value by setting -0,2Nm so that the value on the screen
will be the same as the value on the tester. If it's lower than 0.3Nm, you need to set +0.3Nm and so on.
You can choose between the following units of measurements: Nm and lb.in.
22) Unit:
23) Torq min – Minimum torque:
set the acceptable torque range for each single application. When the reached torque is inside this range,
"tightening OK" will be displayed on the status bar and the green led will light up. If the reached torque is
outside this range the messages "error minimum torque" or "error maximum torque" will be displayed. You
can set the torque range from 0 Nm to 40 Nm at intervals of 0.01 Nm.
The minimum torque option allows to set the lowest value of the torque range and it's on if calibration is
'ON'.
If calibration is 'OFF' the minimum torque value automatically sets on 0Nm.
- - - - - M E N U - - P R : 1 - - - - -
2 4 ) T o r q m a x : 4 0 . 0 0 N m
2 5 ) I n s .
2 6 ) F u n c
24) Torq max – Maximum Torque:
to set the acceptable torque range for the single application. When the reached torque is inside this range,
"right screwing" will be displayed on the status bar and the green led will light up. The messages "below
minimum torque" or "over maximum torque" will be displayed if the reached torque is outside this range.
You can set the torque range from 0 Nm to 40 Nm at intervals of 0.01 Nm.
The maximum torque option allows to set the highest value of the torque range and it's on if the calibration
is 'ON'.
If the calibration is 'OFF' the maximum torque value automatically sets on 40Nm.
25) Ins. barcode: You can scan a barcode and recall the desired program. To be used in
combination with option 4 of the Sequence Menu.
THE FOLLOWING MENU IS AVAILABLE ON TA VERSION ONLY
26) Func T&A–T&A function mode: You can activate the Torque & Angle function.
you do not want to use this function. If you set ON you can choose among six working conditions (see T&A
specific instructions).
Manual EDU 2AE/TOP e EDU 2AE/TOP/TA Rev.0
This function allows an increase or decrease of the displayed torque
The minimum torque and maximum torque options allow the user to
b a r c o d e
T & A :
The minimum torque and maximum torque options allow the user
0 . 0 0 N m
N m
0 . 0 0 N m
O F F
Set OFF if
Pagina 8
